Description
The overall design of the car shell has a strong muscle feel, especially the bulge design at the front cover, which looks extremely aggressive. The anti-roll frame PVC car shell is sturdy and crash-resistant with a spare tire.
Tough nylon material, good playability, crash plate cavity-type crash beam design, more effective absorption of impact.
The chassis is made of sturdy 3mm 6061 aluminium alloy, which guarantees high-speed driving. The side guards are designed to cooperate with the car shell to isolate most of the sand and stone.
The steering adopts the C seat design, which has a small virtual position, and the whole vehicle has a metal coupling. The front suspension adopts a CVD transmission structure, which can make the transmission smoother and have a larger steering angle. The rear suspension adopts dog bone transmission for better performance.
Front and rear metal arm codes have a qualitative improvement in suspension durability. In order to try to reduce the possible damage to the gearbox and arm codes from a rear collision, a T-shaped reinforcement (also a battery compartment) is used to utilize the chassis The strength of the wave box, arm code to a backward force to strengthen.
The design of the servo protector better solves the possibility of the steering gear problem when the steering is under a large torque, and the steering assembly is popped to protect the steering gear.
The car uses medium-difference components, which can make the car have better cornering ability and posture in the corners. At the same time, the metal motor teeth are equipped with nylon large teeth to have better transmission performance and quiet performance.
Front and rear nylon hydraulic suspension, with universal off-road tires, diameter 110MM, width 45MM, suitable for a wide range of cement roads, dirt roads, sandy roads can travel without obstacles.
Hobbywing MAX10 120A full waterproof ESC
3300KV 3652 waterproof brushless motor,
15KG waterproof steering gear
powerful power, about 80KM / H per hour,
Comes complete with Battery and charger
Specifications:
.Material: PC + Metal + Rubber
.Scale: 1/10
.Drive: 4WD
.Wheelbase: 325mm
.Tread: 220mm
.Ground Clearance: 40mm
.Tire Width: 45mm
.Tire Diameter: 110mm
.ESC: Hobbywing MAX10 120A fully waterproof
.Motor: 3660 3600KV brushless motor
.Steering Gear: 15KG
.Speed: 80KM / H
.Remote Control: MT303
.Frequency: 2.4G
.Channel: 3CH
.Remote Control Battery: 8 x AA (Not Included)
.Product Dimensions: 55 x 29.5 x 18cm
.Product Weight: 3000g
.Package Dimensions: 56 x 33 x 22cm
WARNING:PRODUCT SAFETY
This product is not a toy. It is not recommended for children under 14 years old and any minor should be accompanied by and adult when operating.
Requires 8x AA Batteries
